Phifer Sheerweave 4500/4600

Phifer Sheerweave 4500 and 4600 - Vinyl Covered Polyester Solar Screen

Using advances in polyester yarn development, Styles 4500 and 4600 are thinner and lighter weight, allowing for ease of fabrication. Both styles are full basketweaves, making them ideal for applications that require a more opaque and non-directional fabric. Styles 4500/4600 can also be used in exterior roller shades.

Phifer Sheerweave 4500/4600



Special Order Item - Call to Place - 714 321 8109

Phifer Sheerweave Styles 4500 and 4600 Shades
Phifer Sheerweave 4500 and Phifer Sheerweave 4600 Colors





Phifer SheerWeave 4500/4600 Specifications

Phifer SheerWeave 4500

Available Widths: 63 " & 98"
Roll Length: 30 Yards
Mesh Weight: 14.4 (oz./sqyd)
Yarn Diameter: (in) .013 Warp, .013 Fill
Fabric Thickness: (in) .024
Openness Factor: Approximately 5%
Uv Blockage: Approximately 95%
Breaking Strength (lb): 181 Warp, 168 Fill
Stiffness (Mg.): 240 Warp, 190 Fill
Composition: 17% Polyester, 83% Vinyl on Polyester.

Phifer SheerWeave 4600

Available Widths: 63 " & 98"
Roll Length: 30 Yards
Mesh Weight: 17.4 (oz./sqyd)
Yarn Diameter: (in) .013 Warp, .020 Fill
Fabric Thickness: (in) .030
Openness Factor: Approximately 3%
Uv Blockage: Approximately 97%
Breaking Strength (lb): 183 Warp, 308 Fill
Stiffness (Mg.): 230 Warp, 439 Fill
Composition: 22% Polyester, 78% Vinyl on Polyester

Interior Sun Control Fabrics
Standard Colors: See Chart
Standard Widths: 63" and 98"
Standard Roll Length: 30 Yards
Fire Classification: California U.S. Title 19 (small scale), ASTM E 84 (class 1), British Standard 5867 Type B, and NFPA 701 TM#1 Small Scale.



Using advances in polyester yarn development, Styles 4500 and 4600 are thinner, lighter weight vinyl coated polyester fabrics offered in 10 decorator colors. Woven in a 2x2 basketweave, these fabrics are ideal for applications where a more opaque and non-directional fabric is needed.



Phifer Sheerweave 4500 and Sheerweave 4600 are Lead Free Flame Retardant Energy Saving Printable and carry a Phifer Warranty



Phifer Sheerweave 4500/4600 - Average Openness 5% & 3%

Phifer Sheerweave 4500 5%
63" x 30 Yards Sheerweave 4500
All Colors
Special Order
Call for Pricing
98" x 30 Yards Sheerweave 4500
All Colors
Special Order
Phifer Sheerweave 4600 3%
63" x 30 Yards Sheerweave 4600
All Colors
Special Order
Call for Pricing
98" x 30 Yards Sheerweave 4600
All Colors
Special Order

Results are typical for the product and are for reference purposes only. This data cannot be used as a certification or specification.

  • Sheerweave 4500/4600 Sample Card$4.00

    Color Swatch Card
    Phifer Sheerweave 4500 4600 Sample Color Card
