Fiberglass insect screen for patios, porches, windows and doors.

Phifer Standard Mesh

Standard mesh screening



This standard fiberglass screen is the mesh applied in most window and doors. Easily fabricated, this high-quality standard mesh is the preferred insect screening in the fenestration industry.

We carry only Phifer Incorporated Standard Mesh fiberglass insect screen, Ask for Phifer by name.


Technical Information:

Mesh: Standard Mesh Fiberglass Insect Screen (Known as 18x16)

Standard Window Screen Mesh
Colors: Charcoal and Silver-Gray
Roll Length: 100' & 600' Select Sizes 300'
Widths: 18"-96"

Yarn Diameter (inch) .010 - .011

Fabric Thickness (inch) .0125

Openness (%) 59

Light Transmission 69%

Burst Strenght (psi) 92

Aperture: .0027



1814 fiberglass insect screen colors

Phifer Insect Screen and Solar Screen Materials are Made in the USA

Installation:

Standard Mesh Fiberglass is the traditional fiberglass screen mesh for most window and door applications. Standard mesh fiberglass is considered the standard in the window manufacturing industry.

Sizes & Colors:

Standard mesh fiberglass comes in 18", 24", 30", 36", 42", 48”, 54", 60”, 72”, 84" and 96" widths. We stock both Charcoal and Silver/Gray

Warranty:

Phifer will warranty product that does not meet their respective production tolerances and loss of dimentional stability including mildew and rot from exposure conditions outside normal atmospheric pollution or other debris. Warranty Disclaimer: We sell only 1st quality Phifer material. However, Phifers grading criteria allows for various defects within a roll. Roll lengths are not always continuous. Rolls may be up to two pieces per roll to account for specified footage. Warranty does NOT cover use and abuse of materials. Extended Limited Warranty varies by item so call for specific warranty concerns by product.

Benefits:

• 18x16 is the most affordable of all window screen mesh materials

• 18x16 is available in 100', 300' and 600' rolls

• 18x16 is the traditional screen mesh for the window and door indusrty

• 18x16 fiberglass insect screen is made in the USA



Standard mesh fiberglass insect screen 18x16



Please read carefully: Due to a global shortage of Standard Mesh .010-.011 Fiberglass core yarn, "18x16 Charcoal and Gray Fiberglass" will be made with a braided polyester core yarn. Braided polyester will look similar and provide the same level of quality and performance. We have noticed a slightly better outward appearance and clarity with the polyester. We will ship Fiberglass while supplies lasts but polyesters will be shipped in-lieu of fiberglass for 2022-2023 until fiberglass availability and supply chain issues are resolved. Call with questions.
