Phifer Sheerweave 4901 and 4903

Phifer Sheerweave 4901/4903

Phifer Sheerweave Style 4901 & 4903



Using thin and lightweight vinyl-coated polyester yarns, SheerWeave 4901 and 4903 are as versatile as they are beautiful. These sun control fabrics can be used for interior and exterior shading systems.

Phifer Sheerweave 4901 & 4903 Brochure


Technical Information:

Phifer SheerWeave 4901

Available Widths: 63" & 98"
Roll Length: 30 Yards
Composition: 17% Polyester 83% Vinyl on Polyester
Mesh Weight: 16.2 oz/yd2 549.27 g/m2
Fabric Thickness: (in) .028 .71mm
Openness Factor: Approximately 1%
Uv Blockage: Approximately 99%

Phifer SheerWeave 4903

Available Widths: 63" & 98"
Roll Length: 30 Yards
Composition: 17% Polyester 83% Vinyl on Polyester
Mesh Weight: 14.9 oz/yd2 505.2 g/m2
Fabric Thickness: (in) .027 .69mm
Openness Factor: Approximately 3%
Uv Blockage: Approximately 97%



Phifer Sheerweave 4901 and 4903 Colors





Fire Classification: California US Titl 19 (small Scale) NFPA 101 (Class A Rating) CAN/ULC-s 109 (Large and Small Scale) NFPA 701 TM#1 (smallscale) IBC Section 803.1.1 (Class A Rating) NFPA 701 TM#2 (large scale) CAN/CGSB2-4.162-M80 (Fire Clasifications are subject to change. It is the users responsibility to check for the most current fire ratings. Available upon request)



Warranty Disclaimer: We sell only 1st quality Phifer material. However, Phifers grading criteria allows for various defects within a roll. Roll lengths are not always continuous. Rolls may be up to two pieces per roll to account for specified footage.



Special Order Items:

Phifer Sheerweave is a Special Order Item. Please give us a call for pricing and availability. We can normally have rolls received and shipped within 2-5 business days.
